Ethernet Protocols: HTTP(S)
BootP
DHCP
DNS
SNTP
FTP(S)
SNMP
Visualization: Web-Visu
CPU: 32-bit
Programming Languages: Instruction List (IL) according to IEC 61131-3
Ladder Diagram (LD)
Function Block Diagram (FBD)
Continuous Function Chart (CFC)
Structured Text (ST)
Sequential Function Chart (SFC)
Programming Environment: WAGO-I/O-PRO V2.3 (based on CODESYS V2.3)
Configuration Options: WAGO-I/O-CHECK
Web-based management
CODESYS libraries
Transmission Rate: 10/100 Mbit/s
Transmission Medium (Communication/Fieldbus): Twisted pair S-UTP; 100 Ω; Cat. 5; maximum cable length 100 m
Transmission Performance: Class D according to EN 50173
Program Memory: 4 MB
Data Memory: 4 MB
Non-volatile Software Memory: 32 KB
Maximum number of modules per node: 250
Maximum number of modules without bus extension: 64
Input/Output Process Image (Fieldbus): Max. 1020 words/1020 words
RTC Backup during power failure: 6 days (minimum)
Indicators: LED (LINK/ACT) green: Network connection via port 1…2; LED (MS, NS) red/green: Node, network status; LED (I/O, USR) red/green/orange: Local data bus status, user programmable status; LED (A, B) green: System power status, field power status
Supply Voltage (System): 24 VDC (-25…+30%); via pluggable connector (CAGE CLAMP® connection)
Input Current (typical): 500 mA at rated load (24 V)
Power Efficiency (typical): 90% at rated load (24 V)
Current Consumption (5 V system power): 390 mA
Total Current (system power): 1700 mA
Supply Voltage (Field): 24 VDC (-25…+30%); powered via power jumper contacts
Current carrying capacity (power jumper contacts): 10A
Number of output power jumper contacts: 3
Isolation voltage: 500 V system/field
Ethernet Protocols: HTTP(S)
BootP
DHCP
DNS
SNTP
FTP(S)
SNMP
Visualization: Web-Visu
CPU: 32-bit
Programming Languages: Instruction List (IL) according to IEC 61131-3
Ladder Diagram (LD)
Function Block Diagram (FBD)
Continuous Function Chart (CFC)
Structured Text (ST)
Sequential Function Chart (SFC)
Programming Environment: WAGO-I/O-PRO V2.3 (based on CODESYS V2.3)
Configuration Options: WAGO-I/O-CHECK
Web-based management
CODESYS libraries
Transmission Rate: 10/100 Mbit/s
Transmission Medium (Communication/Fieldbus): Twisted pair S-UTP; 100 Ω; Cat. 5; maximum cable length 100 m
Transmission Performance: Class D according to EN 50173
Program Memory: 4 MB
Data Memory: 4 MB
Non-volatile Software Memory: 32 KB
Maximum number of modules per node: 250
Maximum number of modules without bus extension: 64
Input/Output Process Image (Fieldbus): Max. 1020 words/1020 words
RTC Backup during power failure: 6 days (minimum)
Indicators: LED (LINK/ACT) green: Network connection via port 1…2; LED (MS, NS) red/green: Node, network status; LED (I/O, USR) red/green/orange: Local data bus status, user programmable status; LED (A, B) green: System power status, field power status
Supply Voltage (System): 24 VDC (-25…+30%); via pluggable connector (CAGE CLAMP® connection)
Input Current (typical): 500 mA at rated load (24 V)
Power Efficiency (typical): 90% at rated load (24 V)
Current Consumption (5 V system power): 390 mA
Total Current (system power): 1700 mA
Supply Voltage (Field): 24 VDC (-25…+30%); powered via power jumper contacts
Current carrying capacity (power jumper contacts): 10A
Number of output power jumper contacts: 3
Isolation voltage: 500 V system/field
